Запчасти Komatsu 230 МАРКИРОВКА (ITALY) МАРКИРОВКА

Схема запчастей Komatsu 230 - МАРКИРОВКА (ITALY) МАРКИРОВКА
20
21
14
15
13
26
27
x
x
a
a
b
b
c
c
22
17
16
19
18
23
24
25
5
6
2
4
1
3
7
11
8
9
10
12
28
29
40
39
30
38
33
36
34
35
31
37
32

Артикул

Название

Примечание

Количество

1

816212879

PLATE, INSTRUCTION, FUEL

2

816212270

PLATE, BLADE CONTROL

3

816212630

PLATE, INSTRUCTION OF CONTROLS (ONLY FOR CANOPY)

4

816212460

PLATE, HYDRAULIC OIL FILTER

5

816212271

PLATE, FUEL CONTROL LEVER

6

816212475

PLATE, SAFETY HYDRAULIC CAP

7

816212874

PLATE, INSTRUCTION, RADIATOR CAP

8

816212878

PLATE, LUBRICATING TABLE

9

816212888

PLATE, INSTRUCTION, AIR FILTER

10

816212885

PLATE, INSTRUCTION, RADIATOR WATER LEVEL

11

816212904

PLATE, FR. SIDE R.H.

12

816212880

PLATE, OPERATING, LUBRICATION

13

816212899

PLATE, R.H.

14

816212471

PLATE, SAFETY RADIATOR CAP

15

816212902

PLATE, REAR S. R.H.

16

816212881

PLATE, CAUTION TURNING AREA

17

816212131

MARK PLATE

18

816212473

PLATE, SAFETY ENGINE COVER

19

816212345

MARK PLATE, FAI

20

816212901

PLATE, REAR S. L.H.

21

816212855

MARK PLATE, SOUND POWER LEVEL

22

816212898

PLATE, L.H.

23

816212915

PLATE, OPERATING, 3 WAY VALVE

24

816212882

PLATE, CLOSING DOOR (ONLY FOR OPERAT.)

25

816212130

MARK PLATE, FAI

26

816212811

PLATE, SAFETY START. AND LEAVING SEAT

27

816212873

PLATE, OPERATING SWING LOCK LEVER

28

816212478

PLATE, SAFETY BEFORE OPERATING MACHINE

29

816212839

PLATE, MAINTENANCE TABLE

30

816212385

PLATE, LEVER LOCK

31

816212470

PLATE, NAME (LIMITED SUPPLY)

32

801570027

RIVET

33

816212382

PLATE, OPERATING SWING LOCK LEVER

34

816212883

PLATE, CHARGE ON TRAILER

35

816212870

PLATE, TRACK TENSION

36

816212389

MARK PLATE, SOUND PRESSURE LEVEL (ONLY FOR CANOPY)

37

816212521

MARK PLATE, SOUND POWER LEVEL (ONLY FOR OPERAT.)

38

816212810

PLATE, OPERATING WORK EQUIPMENT (ONLY FOR OPERAT.)

39

816212451

PLATE, CAUTION FUEL FILTER

40

816212486

PLATE, CAUTION ENGINE OIL FILTER

Выбрано товаров: 40
