Запчасти Komatsu 222 6-СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН (3 ЧАСТЬ) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

844230009

CONTROL VALVE, ASSY.

1

844120234

ARM SECTION, ASSY.

2

844120210

KIT, GASKET

3

844120214

CONTROL UNIT, ASSY.

4

844120215

SPRING

5

844120216

SPRING

6

855021021

O-RING

7

844120212

PLUG

8

844120213

SPRING

9

844120211

VALVE

10

844120217

SAFETY AND SUCTION VALVE, ASSY.

11

844120218

KIT, GASKET

12

844120235

BUCKET SECTION, ASSY.

13

844120210

KIT, GASKET

14

844120214

CONTROL UNIT, ASSY.

15

844120215

SPRING

16

844120216

SPRING

17

855021021

O-RING

18

844120212

PLUG

19

844120213

SPRING

20

844120211

VALVE

21

844120217

SAFETY AND SUCTION VALVE, ASSY.

22

844120218

KIT, GASKET

23

844120236

CAP, ASSY.

24

844120237

KIT, GASKET

25

844120238

BOOM SECTION, ASSY.

26

844120210

KIT, GASKET

27

844120214

CONTROL UNIT, ASSY.

28

844120215

SPRING

29

844120216

SPRING

30

855021021

O-RING

31

844120212

PLUG

32

844120213

SPRING

33

844120211

VALVE

34

844120217

SAFETY AND SUCTION VALVE, ASSY.

35

844120218

KIT, GASKET

36

844120236

CAP, ASSY.

37

844120237

KIT, GASKET

|A

SEE FIG. 7020
