Запчасти Komatsu 222 РАДИАТОР И ТРУБЫ КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

875001073

RADIATOR, ASSY.

2

875001074

PLUG

3

500044365

PIPE

4

500366043

PLUG

5

855661170

O-RING

6

500158707

CONVEYOR

7

802170001

WASHER

8

802150508

SPRING WASHER

9

801015084

BOLT

10

200536856

SUPPORT FRONT

11

801015109

BOLT

12

802170002

WASHER

13

801015086

BOLT

13

801015086

BOLT

13

801015087

BOLT

14

802170001

WASHER

14

802170001

WASHER

14

802148009

WASHER

15

200536855

SUPPORT, REAR

15

200537080

SUPPORT, REAR

16

802660010

HOSE-CLAMP

17

852951047

SLEEVE

18

852951050

SLEEVE

19

200767459

PIPE

20

852951051

SLEEVE

21

801015535

BOLT

22

802150506

SPRING WASHER

23

802170000

WASHER

24

500411536

SHEET, L.H.

25

500411537

SEAT, UPPER

26

500411538

SHEET, R.H.

27

801015084

BOLT

28

802170001

WASHER

29

816213121

GASKET

30

500411539

SHEET

31

500411540

SHEET

32

500159234

COVER

|A

SEE FIG. 7110
