Запчасти Komatsu 222 ТОПЛИВН. ВПРЫСК ОБОРУД-Е (DIESEL) ДВИГАТЕЛЬ
3
1
4
5
6
7
15
16
8
17
2
9
22
18
10
11
19
20
21
12
13
23
14
25
32
31
30
29
24
28
27
26
№
Артикул
Название
Примечание
Количество
1
PKP000487
INJECTION PUMP
2
BODY
3
PKP000502
HOLDER
4
PKP000503
O-RING
5
PKP000504
SPRING
6
PKP000505
GASKET
7
PKP000506
VALVE
8
PKP000507
ELEMENT
9
PKP000508
SLEEVE
10
PKP000509
WASHER
11
PKP000510
SPRING
12
PKP000511
WASHER
13
PKP000512
PLATE
14
PKP000513
TAPPET
15
PKP000514
COVER
16
PKP000515
SCREW
17
PKP000516
WASHER
18
PKP000517
PIN
19
PKP000518
RACK
20
PKP000519
BOLT
21
PKP000520
CONNECTION
22
PKP000521
GASKET
23
PKP000522
PIN
24
PKP000499
ATOMISER
25
PKP000530
NUT
26
PKP000523
NUT
27
PKP000524
GASKET
28
PKP000525
SHIM
29
PKP000526
SPRING
30
PKP000527
WASHER
31
PKP000528
SPACER
32
PKP000529
NOZZLE
Выбрано товаров: 32
