Запчасти Komatsu 222 НИЗ. PRESSURE ТОПЛИВН. СИСТЕМА (1 ЧАСТЬ) ДВИГАТЕЛЬ
11
A
15
17
15
14
4
10
15
10
1
11
3
16
15
2
11
18
11
8
5
9
11
7
13
12
6
23
19
20
22
18
20
21
№
Артикул
Название
Примечание
Количество
1
PKP000008
LIFT PUMP
2
PKP000355
JOINT
3
PKP000144
SCREW
4
PKP000356
CONNECTION
5
PKP000006
FILTER
6
PKP000007
ENGINE FUEL FILTER
7
PKP000358
PLUG
8
PKP000406
SCREW
9
PKP000269
WASHER
10
PKP000360
BOLT
11
PKP000361
WASHER
12
PKP000268
NUT
13
PKP000270
WASHER
14
PKP000363
HOSE
15
PKP000364
BRIDLE
16
PKP000365
CONNECTION
17
PKP000589
PIPE, FUEL
18
PKP000590
BRACKET
19
PKP000591
STAY
20
PKP000362
SCREW
21
PKP000494
SCREW
22
PKP000105
NUT
23
PKP000625
WATER SEPARATOR
|A
SEE FIG. 1190
