Запчасти Komatsu 222 ГИДРОЛИНИЯ СЕРВОУПРАВЛ. (1 ЧАСТЬ) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

500358702

FLANGE 90ш

2

855021809

O-RING

3

801105117

SCREW

4

802130006

WASHER

5

500365402

PLUG

6

852951193

HOSE

7

500353508

ELBOW

8

855670004

O-RING

9

845340007

FEED UNIT, ASSY.

10

801104078

SCREW

11

802150506

SPRING WASHER

12

392058062

HOSE

13

500358788

UNION

14

855670004

O-RING

15

500353505

ELBOW

16

855670006

O-RING

17

852951190

HOSE

18

500351744

UNION

19

855051111

O-RING

20

500355608

ELBOW

21

852951189

HOSE

22

500355155

UNION

23

855670006

O-RING

24

500365503

PLUG

25

802090014

GASKET

26

500351745

UNION

27

855051113

O-RING

28

500365502

PLUG

29

802090010

GASKET

30

500591064

BLOCK

31

801015108

BOLT

32

802150510

SPRING WASHER

33

392369001

HOSE

34

500368269

ELBOW

35

855670004

O-RING

36

844230003

CONTROL VALVE, ASSY.

37

802150508

SPRING WASHER

38

801015086

BOLT

39

500355912

UNION

40

200343220

PLUG

|A

SEE FIG. 7210

|B

SEE FIG. 5080
