Запчасти Komatsu 22-BCM-1 PILE ПРИВОДR LEADER (ДЛЯ D-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

22-580256-00

P/D LEADER ASS'Y

1

22-595709-21

SECTION,UPPER¤ 6M

2

22-595710-21

SECTION,INTERMEDIATE¤ 5M

3

22-595711-21

SECTION,INTERMEDIATE¤ 6M

4

22-595712-21

SECTION,LOWER¤ 0.75M

5

01901-01200

BOLT

6

01970-11225

NUT

7

01601-03179

WASHER

8

22-595713-21

BRACKET,L.H.

9

22-595714-21

BRACKET,R.H.

10

01900-10550

BOLT

11

01970-10513

NUT

12

01602-01648

WASHER

13

22-595715-00

TOP SHEAVE ASS'Y

14

01900-11285

BOLT

15

01970-11225

NUT

16

01601-03179

WASHER

17

22-595716-00

SHEAVE ASS'Y

18

01900-10540

BOLT

19

01970-10513

NUT

20

01602-01648

WASHER

21

22-595717-00

CATCH FORK ASS'Y

22

01900-10550

BOLT

23

01970-10513

NUT

24

01602-01648

WASHER

|25

22-580268-00

SECTION ASS'Y,(3M) (OP)

25

22-540465-21

SECTION,LEADER¤ 3M

26

01901-11200

BOLT

27

01970-11225

NUT

28

01601-03179

WASHER

|29

22-580269-00

SECTION ASS'Y,CATCH FORK (OP)

29

22-451051-21

SECTION,CATCH FORK¤ 0.6M

30

01900-10565

BOLT

31

01970-10513

NUT

32

01602-01648

WASHER
