Запчасти Komatsu 212 7-СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН (1 ЧАСТЬ) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

890000003

CONTROL VALVE, ASSY.

\0

890000049

CONTROL VALVE, ASSY.

1

BLOCK

2

BLOCK

3

BLOCK

4

BLOCK

5

BLOCK

6

BLOCK

7

855661166

O-RING

8

890001067

TIE-ROD

9

801920104

NUT

10

SPOOL, BOOM

11

SPOOL, BUCKET

12

SPOOL, TRAVEL

13

SPOOL, BLADE

14

SPOOL, ARM

15

SPOOL, SWING

16

890001055

GASKET

17

890001018

PLATE

18

890001019

SPACER

19

890001020

COLLAR

20

890001022

SPRING

21

890001100

SCREW

22

890001023

COVER

23

890001101

SCREW

24

890001102

SCREW

25

890001103

BALL

26

890001024

SPRING

27

890001025

PLUG

28

890001058

PLUG

29

855021616

O-RING

30

890001026

PLUG

31

890001027

O-RING

32

890001179

O-RING

33

890001105

PLUG

34

890001179

O-RING

35

890000017

VALVE ASSY., MAIN RELIEF

36

890000016

VALVE ASSY., SUCTION AND SAFETY

37

890000015

VALVE ASSY., SUCTION AND SAFETY

37

890000014

VALVE ASSY., SUCTION AND SAFETY

38

890001005

PLUG

39

855021211

O-RING

40

855021015

O-RING
