Запчасти Komatsu 212 КАБИНА (3 ЧАСТЬ) ЧАСТИ КОРПУСА И КАБИНА

\0

816010388

OPERATOR'S CAB, ASSY.

1

816212531

DOOR, ASSY.

2

816024400

GLASS, DOOR

3

816212542

SEAL, GLASS-WINDOW

4

816212560

MARK AND PLATE

5

801250042

SCREW

6

816212551

HANDLE

7

816212549

PLUG

8

816212547

PANEL FOR DOOR

9

801200698

BOLT

10

802070008

WASHER

11

801852208

NUT

12

816210643

LOCK, BLOCK

13

816212548

COVER, LOCK

14

801370065

SCREW

15

801852206

NUT

16

802070006

WASHER

17

816210650

BRACKET FOR HANDLE

18

816210651

GASKET

19

816210652

GASKET

20

801160131

SCREW

21

816212553

HANDLE, ASSY.

22

816212432

BLOCK

23

816212433

WRENCH

24

816211581

STRIKER LOCK

25

802070012

WASHER

26

802150512

SPRING WASHER

27

816210648

NUT

28

816210678

PIN, ASSY.

29

816210684

FITTING

30

816212549

PLUG

31

816212546

PANEL, LATERAL, R.H.

32

816212545

PANEL, UNDER-ROOF

33

816212543

SEAL, DOOR

34

801852206

NUT

35

802070006

WASHER

36

816211538

BUSHING, STOPPING GLASS

37

801250061

SCREW

38

816211680

PLATE
