Запчасти Komatsu WB98A-2 РЫЧАГИ УПРАВЛ-Я ЭКСКАВАТ. КОВШОМ СИСТЕМА УПРАВЛЕНИЯ

1

360705636

COVER

2

801250260

SCREW

3

816212687

WASHER

4

360705069

MAT

5

314516600

GASKET

6

360705056

PLATFORM

7

801015108

BOLT

8

802120010

SPRING WASHER

9

802148013

WASHER

10

802640716

KNOB

11

314513600

LEVER

12

312648787

BOOT

13

802640718

KNOB

14

312313662

LEVER

15

500022698

PIN

16

200514036

CONNECTION, R.H.

17

200514036

CONNECTION, R.H.

18

500611563

JOINT

19

805850016

JOINT

20

801015089

BOLT

21

500044125

SPACER

22

801880208

NUT

23

802720018

FORK

24

802725018

PIN

25

801920104

NUT

26

801024092

BOLT

27

802130014

WASHER

28

390205079

TIE-ROD

29

390205080

TIE-ROD

30

801015090

BOLT

31

802170001

SPRING WASHER

32

314501050

SUPPORT

33

801015110

BOLT

34

802150010

SPRING WASHER

35

314501620

SUPPORT

36

801015111

BOLT

37

801880001

NUT

38

844010242

CONTROL VALVE, ASSY.

39

801015568

BOLT

40

801920105

NUT

41

801713411

NUT

42

885411049

GROMMET

43

804020008

SPRING

44

200514035

LOCKING

45

802510113

PEG

46

200329098

PIN

47

500022888

LEVER

48

802640722

KNOB

49

816212265

KNOB

50

801703408

NUT

51

200496250

LEVER, R.H.

52

200496250

LEVER, L.H.

53

816211398

BOOT

54

500044354

SPACER

55

802070012

WASHER

56

802610057

PIN, COTTER
