Запчасти Komatsu WB98A-2 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

360787050

OPERATOR'S CAB, ASSY.

1

801200697

SCREW

2

816213477

WASHER

3

816213478

RUBBER

4

360705082

CANOPY

5

801014124

BOLT

6

816213479

RUBBER

7

816213480

GASKET

8

816213416

GASKET

9

816213417

GASKET

10

816024477

GLASS, REAR, R.H.

11

816024476

GLASS, LATERAL

12

816024473

GLASS, DOOR, R.H.

13

816024491

GLASS, DOOR, L.H.

14

816213405

FRAME, DOOR, R.H.

15

816213404

FRAME, DOOR, L.H.

16

816213406

SEAL, DOOR, R.H.

17

816213481

SEAL, DOOR, L.H.

18

816213415

SEAL

19

816024474

GLASS, FRONT, CENTRAL

20

816024475

GLASS, FRONT, ASSY.

21

816213482

GASKET, UPPER

22

816213423

GASKET, UPPER

23

816213419

FRAME, REAR WINDOW

24

816024478

GLASS, REAR, FIXED

25

816024479

GLASS, REAR, CENTRAL

26

816213483

SEAL, REAR

27

816213421

GASKET, LATERAL, INNER

28

816213422

GASKET, LATERAL

29

816024480

GLASS, REAR, LOWER

30

816214341

DOOR, L.H., ASSY.

31

816214340

DOOR, R.H., ASSY.

32

816024492

GLASS, ASSY

33

816024493

GLASS, ASSY

34

816213418

DOOR, REAR, ASSY.

35

816213950

WASHER

36

855711069

GASKET

37

801015136

BOLT

38

802120012

SPRING WASHER

39

802170003

WASHER

40

855711071

GASKET
