Запчасти Komatsu WB98A-2 РАМА РАМА

1

360701051

FRAME, FRONT

2

360701053

COVER

3

360701700

PLATE

4

801014268

BOLT

5

801852220

NUT

6

500114316

CONNECTING ROD

7

802620100

PIN, COTTER

8

360701060

FRAME, REAR

9

360701325

WINDOW, R.H.

10

816212939

HINGE

11

802700009

RETAINER

12

360701318

WINDOW, L.H.

13

816212939

HINGE

14

802700009

RETAINER

15

801015108

BOLT

16

802120010

SPRING WASHER

17

802170002

SPRING WASHER

18

360701701

PLATE

19

855710069

GASKET

20

500611640

RUBBER

21

360701755

SUPPORT

22

801015111

BOLT

23

802150010

SPRING WASHER

24

801015113

BOLT

25

360701757

COVER

26

801220209

SCREW

27

802120006

SPRING WASHER

28

802170000

WASHER

29

816215037

PLUG

30

801880001

NUT

31

801880208

NUT

32

805850016

JOINT

33

500044125

SPACER

34

801015088

BOLT

35

360701721

TIE-ROD

36

801940331

CAP

37

360701735

COVER

38

801015084

BOLT

39

802120008

SPRING WASHER

40

360705696

R.H. CLOSURE

41

801880208

NUT

42

802170001

SPRING WASHER

43

360705697

COVER, L.H.

44

360715656

R.H. HINGE

45

360715053

L.H. HINGE

46

855710058

GASKET

47

801940112

PLUG
