Запчасти Komatsu WB98A-2 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu WB98A-2 - ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ
32
44
32
25
38
49
36
34
32
34
32
A
A
53
54
51
45
46
26
46
48
38
36
35
47
52
42
39
34
31
43
38
29
35
36
34
27
41
31
43
28
29
35
40
41
28
31
43
1
68
30
38
68
35
36
41
28
61
31
43
59
29
57
39
58
24
41
2
22
60
20
19
21
3
13
23
18
16
69
17
67
12
9
66
4
5
55
11
56
65
63
64
8
67
7
15
14
62
2
3

Артикул

Название

Примечание

Количество

\0

871070031

ENGINE, ASSY.

1

YM123901-03090

PIPE

2

YM123900-07900

LIFTER

3

YM26106-100202

BOLT

4

YM723900-11100

HEAD,ASSY.

5

CYLINDER HEAD

7

YM123900-11080

SEAT

8

YM123900-11090

SEAT

9

YM119000-11810

GUIDE VALVE

11

YM23871-005000

PLUG

12

YM27241-400000

PLUG

13

YM27310-090000

COTTER

14

YM123900-11100

VALVE, INLET

15

YM123900-11110

VALVE EXHAUST

16

YM123900-11120

SPRING

17

YM121850-11150

SEAL, VALVE

18

YM121850-11180

RETAINER, SPRING

19

YM119171-11370

CAP VALVE

20

YM119625-11870

PROTECTION, NOZZLE

21

YM119625-11880

SEAT, NOZZLE

22

YM119625-11900

RETAINER

23

YM26216-060302

STUD

24

YM26366-060002

NUT

25

YM24311-000320

O-RING

26

YM123900-11200

SUPPORT COMP, ROCKER

27

YM123900-11240

ROCKER SHAFT

28

YM119000-11280

SPRING

29

YM123900-11510

SUPPORT

30

YM123900-11520

SUPPORT

31

YM123900-11650

ROCKER SHAFT, SUCTION

32

YM129150-11230

SCREW

34

YM129150-11750

NUT

35

YM123900-11660

ROCKER SHAFT, EXHAUST

36

YM129150-11230

SCREW

38

YM129150-11750

NUT

39

YM22242-000180

RING, SNAP

40

YM26577-040162

SCREW

41

YM119593-11300

BOLT

42

YM26106-080702

BOLT

43

YM26366-080002

NUT

44

YM124160-01751

PLUG

45

YM123900-11331

BONNET ASSY., HEAD

46

YM129150-03070

SPLASH-GUARD

47

YM123900-03202

PLATE

48

YM123900-03210

GASKET

49

YM123900-03220

PIPE

51

YM123900-11310

GASKET

52

YM26022-050122

SCREW

53

YM124160-11360

PLUG

54

YM24311-000120

O-RING

55

YM23297-350121

RETAINER

56

YM26106-120202

BOLT

57

YM123901-03270

BREATHER, ASSY.

58

YM123901-03240

FILTER

59

YM123901-03250

COVER

60

YM123901-03260

BREATHER

61

YM26116-050102

BOLT PLATED

62

YM123901-03280

UNION

63

YM119773-03300

PIPE, ASSY.

64

YM119773-03250

PIPE

65

YM119773-03270

PIPE

66

YM127605-03400

PIPE

67

YM23000-016000

CLAMP

68

YM23000-041000

COLLAR

69

YM23000-041000

COLLAR

Выбрано товаров: 65
