Запчасти Komatsu WB98A-2 РУЧН. БЫСТРОСЪЕМН. МЕХ-М РАБОЧЕЕ ОБОРУДОВАНИЕ

1

360702053

TIE-ROD

2

860010007

FITTING

3

390601048

BUSHING

4

390503142

PIN

5

801015134

BOLT

6

802150512

SPRING WASHER

7

802170003

WASHER

8

360733057

FRAME

9

360733662

PLATE

10

801015084

BOLT

11

802150008

SPRING WASHER

12

360733660

FLANGE

13

801114172

SCREW

14

802130014

WASHER

15

860010001

FITTING

16

360733661

BUSHING

17

360733062

LEVER

18

802510253

SPRING PIN

19

802510201

SPRING PIN

20

360733061

LEVER

21

805630041

BUSHING

22

360733059

TIE-ROD

23

500325296

PIN

24

802610055

PIN, COTTER

25

801703410

NUT

26

802720023

FORK

27

802725023

PIN

28

390613003

BUSHING

29

360733052

PIN

30

360733058

TIE-ROD

31

360733060

LINK

32

360733649

WASHER

33

360733638

PIN

34

802510173

SPRING PIN

35

500114716

LINK

36

801014027

BOLT

37

802148005

WASHER

38

360233633

SPACER

39

801880205

NUT

40

804020006

SPRING

41

360733645

TIE-ROD

42

360733657

PLATE

43

360733063

COVER

44

801015108

BOLT

45

802150010

SPRING WASHER
