Запчасти Komatsu WB97S-5E0 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

42N-54-13800

WINDOW, ASSEMBLY

1

42N-54-13820

GASKET

2

42N-54-13810

GLASS

3

42N-54-13830

HINGE

4

42N-54-14280

GASKET

5

42N-54-14290

GASKET

6

42N-54-14930

WASHER

7

42N-56-14660

SCREW

8

42N-54-13950

HANDLE

9

42N-54-13960

PUFFER

10

42N-54-13980

WASHER

11

42N-54-13970

SPACER

12

42N-54-13990

WASHER

13

42N-54-17270

NUT

14

21D-54-13780

PROTECTION

15

42N-54-13870

SUPPORT

16

42N-54-13880

GASKET

17

42N-54-13890

PLATE

18

42N-54-15830

BOLT

19

21D-09-86180

PROTECTION

20

01640-30610

WASHER

21

395-56-14670

NUT

22

21D-54-13250

SPACER

23

42N-54-13900

HANDLE

24

42N-54-15850

BOLT

25

01640-30610

WASHER

26

395-56-14670

NUT

27

21D-09-86180

PROTECTION

28

42N-54-13930

PAD

29

42N-54-13910

HOOK

30

42N-54-13920

GASKET

31

21D-54-13250

SPACER

32

42N-54-13940

PLATE

33

01640-30610

WASHER

34

395-56-14670

NUT

35

21D-09-86180

PROTECTION

36

42N-54-15151

PIN

37

37A-09-4A009

WASHER

38

395-56-13600

NUT
