Запчасти Komatsu WB97S-5E0 РЫЧАГ УПРАВЛ-Я ПОДАЧЕЙ ТОПЛИВА (/) СИСТЕМА УПРАВЛЕНИЯ

\0

42N-54-14400

LEVER, ASSEMBLY

1

42N-54-14410

SUPPORT

2

42N-54-14430

PIN

3

37A-09-63171

WASHER, SPRING

4

42N-54-14440

WASHER

5

01640-21426

WASHER

6

37A-09-35414

NUT, STOP

7

42N-54-14420

BENT

8

42N-54-14460

KNOB

9

42N-54-17240

SCREW

10

42N-54-14450

GASKET

11

37A-09-1J100

SCREW

12

01640-20816

WASHER

13

01598-00809

NUT

14

42N-54-17110

SCREW

15

42N-43-11440

CABLE

16

37A-09-61019

PIN

17

42N-54-14570

PIN

18

01643-11032

WASHER

19

42N-54-17270

NUT

20

42N-43-15810

LEVER

21

42N-54-14520

BEARING

22

42N-43-15820

BRACKET

23

01016-50825

BOLT

\23

42N-54-14500

TIE-ROD

24

37A-09-5Z019

JOKE

25

21D-09-21430

NUT

26

42N-54-14530

PIVOT

27

42N-56-17610

DAMPER

28

21D-09-21430

NUT

29

37A-09-1T702

SCREW

30

01643-11445

WASHER

31

01643-10823

WASHER

32

21D-09-21720

NUT

33

01598-00809

NUT

34

42N-54-14470

PIVOT

35

37B-09-2C006

SPRING

36

395-56-11H60

RING

37

395-56-11H50

BEARING

38

42N-54-14480

LEVER

39

37A-09-1K105

SCREW

40

42N-54-15620

PEDAL

41

04064-01410

RING

42

42N-54-14580

PAD

43

21D-09-21440

NUT

44

42N-54-19870

GROMMET

45

42N-56-12880

WASHER

46

01640-21016

WASHER

47

04064-01010

RING, SNAP

48

37A-09-61019

PIN

49

01643-10823

WASHER

50

01598-00809

NUT
