Запчасти Komatsu WB97S-5E0 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

42N-54-13800

WINDOW, ASSEMBLY

1

42N-54-13820

GASKET

2

42N-54-13810

GLASS

3

42N-54-13830

HINGE

4

42N-54-14280

GASKET

5

42N-54-14290

GASKET

6

42N-54-13860

WASHER, GASKET

7

37A-09-1J100

SCREW

8

42N-54-17540

CAP

9

42N-54-13950

HANDLE

10

42N-54-13960

PUFFER

11

42N-54-13980

WASHER

12

42N-54-13970

SPACER

13

42N-54-13990

WASHER

14

42N-54-17270

NUT

15

21D-54-13780

PROTECTION

16

42N-54-13870

SUPPORT

17

42N-54-13880

GASKET

18

42N-54-13890

PLATE

19

42N-54-15830

BOLT

20

21D-09-86180

PROTECTION

21

01640-30610

WASHER

22

395-56-14670

NUT

23

21D-54-13250

SPACER

24

42N-54-13900

HANDLE

25

42N-54-15850

BOLT

26

01640-30610

WASHER

27

395-56-14670

NUT

28

21D-09-86180

PROTECTION

29

42N-54-13930

PAD

30

42N-54-13910

HOOK

31

42N-54-13920

GASKET

32

21D-54-13250

SPACER

33

42N-54-13940

PLATE

34

01640-30610

WASHER

35

395-56-14670

NUT

36

21D-09-86180

PROTECTION

37

42N-54-15150

PIN

38

395-56-14600

WASHER

39

395-56-13600

NUT
