Запчасти Komatsu WB97S-5E0 ТРАНСМИССИЯ (7/9) РАМА

Схема запчастей Komatsu WB97S-5E0 - ТРАНСМИССИЯ (7/9) РАМА
7
6
5
4
27
26
3
2
13
12
10
8
8
16
25
9
11
24
23
15
22
21
20
19
14
18
17
1

Артикул

Название

Примечание

Количество

\0

42N-15-11501

TRANSMISSION , ASSEMBLY

1

CA0123918

BOLT

2

CA0129924

WASHER

3

CA0028131

O-RING

4

CA0025809

BEARING

5

CA0024799

SEEGER

6

CA0106866

SHIM, 0.100 MM

6

CA0106867

SHIM, 0.300 MM

6

CA0106868

SHIM, 0.500 MM

7

CA0138391

THRUST WASHER

8

CA0138399

WASHER

9

CA0138394

SPACER

10

CA0028548

O-RING

11

CA0139341

CLUTCH, PISTON

12

CA0028624

O-RING

13

CA0138384

BRAKE PLATE

14

CA0068394

KIT, 4WD OUTPUT SHAFT

15

CA0023834

RIVET

16

CA0139197

SEAL

17

CA0139342

PIN, BRAKE

18

CA0028534

O-RING

19

CA0149305

KIT, CLUTCH

20

CA0141114

LOCK, RING

21

CA0025009

LOCK, RING

22

CA0642122

GEAR

23

CA0027956

ROLLER BEARING

24

CA0139011

SWING CIRCLE

25

CA0025829

BEARING

26

CA0144452

FLANGE

27

CA0025485

SEAL

Выбрано товаров: 30
