Запчасти Komatsu WB97S-5 ТРАНСМИССИЯ (/9) РАМА

Схема запчастей Komatsu WB97S-5 - ТРАНСМИССИЯ (/9) РАМА
12
10
8
6
4
11
9
9
11
13
2
7
8
15
5
10
12
3
1
14
30
18
15
13
17
28
26
19
24
16
22
14
29
27
21
5
43
41
25
39
23
7
44
32
42
4
36
40
20
38
34
31
32
31
33
37
35
33

Артикул

Название

Примечание

Количество

\0

42N-15-11500

DRIVE SHAFT, ASSY.

1

CA0025829

BEARING

2

CA0138985

SWING CIRCLE

3

CA0148642

GEAR

4

CA0025067

RING, SNAP

5

CA0135020

DISK

6

CA0149303

CLUTCH PACK

7

CA0027956

ROLLER BEARING

8

CA0138986

SWING CIRCLE

9

CA0025031

RING, SNAP

10

CA0133912

SPRING LOCK

11

CA0139351

SPRING

12

CA0138984

SLEEVE

13

CA0138983

PISTON

14

CA0139199

SEAL

15

CA0139198

SEAL

16

CA0139197

SEAL

17

CA0148669

SHAFT

18

CA0023834

PLUG

19

CA0024321

SPRING PIN

20

CA0149304

CLUTCH PACK

21

CA0148640

GEAR

22

CA0642121

GEAR

23

CA0025066

RING, SNAP

24

CA0138381

DISK

25

CA0149302

CLUTCH PACK

26

CA0025021

RING, SNAP

27

CA0139347

SPRING LOCK

28

CA0139348

SPRING

29

CA0148647

PISTON

30

CA0145899

SEAL

31

CA0028015

ROLLER BEARING

32

CA0028350

SLEEVE

33

CA0028648

O-RING

34

CA0142923

SEAL

35

CA0148641

THRUST WASHER

36

CA0145900

SEAL

37

CA0148637

GEAR

38

CA0150000

WASHER

39

CA0025860

BEARING

40

CA0025485

SEAL

41

CA0148854

FLANGE

42

CA0028623

O-RING

43

CA0129924

WASHER

44

CA0123918

BOLT

Выбрано товаров: 45
