Запчасти Komatsu WB97S-5 ГИДР. НАСОС. (/) ГИДРАВЛИКА РАБОЧЕЕ ОБОРУДОВАНИЕ

\0

707-1U-00111

HYDRAULIC PUMP, ASSY.

\0

708-1U-01111

PUMP, ASSY.

\0

708-1U-04112

COVER, ASSY.

1

COVER

2

PLUG

3

708-8E-16160

PLUG

4

07002-11023

O-RING

5

07040-11409

PLUG

6

07002-11423

O-RING

7

708-1U-12110

SHAFT

8

BEARING

9

708-1W-42130

GASKET

10

07000-B2065

O-RING

11

708-1U-12320

SEAL

\11

708-1W-05810

KIT, SHIM

12

SHIM, 1.600 mm

12

SHIM, 1.700 mm

12

SHIM, 1.800 mm

12

SHIM, 1.900 mm

12

SHIM, 2.000 mm

12

SHIM, 2.100 mm

12

SHIM, 2.200 mm

13

04065-07225

RING, SNAP

14

07000-B1009

O-RING

15

708-1U-11511

COVER

16

01010-61470

BOLT

17

01643-31445

WASHER

18

04020-01024

PIN

19

706-73-42370

O-RING

20

708-1W-42120

BEARING

21

708-1U-13411

SWASH PLATE

22

04260-01270

BALL

23

708-3T-13421

BALL
