Запчасти Komatsu WB97S-2 ПРИБОРН. ПАНЕЛЬ (/) КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

\0

312612178

LATERAL DASHBOARD, ASSY

1

885081170

PLUG

2

885081169

SWITCH, HORN

3

885141196

GLASS, HORN

4

885141072

BULB

5

885081160

SWITCH, ROTATING BEAM

6

885141103

GLASS, ROTATING BEAM

7

885080076

SWITCH, WIPER

8

885081104

GLASS, WIPER

9

885081160

SWITCH, WORKING BEAM

10

885141203

GLASS, WORKING LIGHT

11

885270769

WIRING, LATERAL BOARD

12

885081157

REAR SPEED CONTROL SWITCH

13

885141072

BULB

14

885141198

POWER GLASS

15

312612056

BOOM CYLINDER LOCKING SWITCH

16

885141072

BULB

17

885141200

BOOM CYLINDER LOCKING GLASS

18

312612055

PLATE LOCKING SWITCH

19

885141072

BULB

20

885141199

PLATE LOCKING GLASS

21

312612219

PLATFORM LINE, ASSY

22

885071034

RETURN TO DIG RELAY

23

885071022

FAN CHARGE RELAY

24

885071049

STOP LIGHTS DIFFERENTIAL LOCKING RELAY

25

885411483

PLATE

26

802070004

WASHER

27

801015013

BOLT

28

312612203

3RD SPEED RELAY (OPTIONAL)

29

312612196

CENTRAL OPERATOR'S SEAT RELAY
