Запчасти Komatsu WB97R-5E0 ТРАНСМИССИЯ (/9) РАМА

Схема запчастей Komatsu WB97R-5E0 - ТРАНСМИССИЯ (/9) РАМА
9
8
7
6
12
5
8
4
11
10
3
11
10
12
2
1
14
15
16
9
13
17
30
14
15
13
28
26
24
19
22
18
21
29
4
27
43
5
41
20
25
39
32
23
7
44
42
36
34
40
32
38
31
31
35
37
33

Артикул

Название

Примечание

Количество

\0

42N-15-11501

TRANSMISSION , ASSEMBLY

1

CA0025829

BEARING

2

CA0138985

SWING CIRCLE

3

CA0148642

GEAR

4

CA0025067

RING, STOP

5

CA0135020

RING, STOP

6

CA0149303

KIT, CLUTCH

7

CA0027956

ROLLER BEARING

8

CA0138986

SWING CIRCLE

9

CA0025031

RING, STOP

10

CA0133912

COVER, SPRING LOCK

11

CA0139351

SPRING

12

CA0138984

SLEEVE

13

CA0138983

PISTON

14

CA0139199

SEAL

15

CA0139198

SEAL

16

CA0068768

KIT, SHAFT

17

CA0023834

RIVET

18

CA0139197

SEAL

19

CA0024321

SPRING PIN

20

CA0149304

KIT, CLUTCH

21

CA0148640

GEAR

22

CA0642121

GEAR

23

CA0025066

LOCK, RING

24

CA0138381

LOCK, RING

25

CA0149302

KIT, CLUTCH

26

CA0025021

LOCK, RING

27

CA0139347

COVER, LOCK-SPRING

28

CA0139348

SPRING

29

CA0148647

CLUTCH, PISTON

30

CA0145899

RING, SEAL

31

CA0028015

NEEDLE, BEARING BUSH

32

CA0028350

BUSH

33

CA0028648

O-RING

34

CA0142923

SEAL, RING

35

CA0148641

SPACER

36

CA0145900

RING, SEAL

37

CA0148637

GEAR

38

CA0150000

WASHER

39

CA0025860

BEARING

40

CA0025485

SEAL

41

CA0148854

FLANGE

42

CA0028623

O-RING

43

CA0129924

WASHER

44

CA0123918

BOLT

Выбрано товаров: 45
