Запчасти Komatsu WB97R-2 ГИДРОЛИНИЯ (РЕГУЛИР. ПЛАВНОСТИ ХОДА) (/) (ОПЦИОНН.) ГИДРАВЛИКА РАБОЧЕЕ ОБОРУДОВАНИЕ

1

312691602

SUPPORT

2

845010307

RIDE CONTROL ELECTRO-VALVE

3

845010312

GASKET KIT

4

885270649

WIRING, ASSY

5

885081155

SWITCH

6

885141225

COVER GLASS

7

885141072

LAMP

8

801015560

BOLT

9

802170002

WASHER

10

855150078

GASKET

11

390021047

UNION

12

855150054

GASKET

13

500360815

UNION

14

855150039

GASKET

15

847001013

ACCUMULATOR

16

500380106

UNION

17

855051111

GASKET

18

855051014

GASKET

19

392400020

HOSE

20

312691601

SUPPORT

21

801015086

BOLT

22

802170001

WASHER

23

845510000

VALVE

24

845010244

GASKET KIT

25

801105113

BOLT

26

802150005

SPRING WASHER

27

845510001

PLATE

28

801105116

BOLT

29

802120006

SPRING WASHER

30

801880206

SELF-LOCKING NUT

31

312691600

UNION

32

855051111

O-RING

33

855051014

O-RING

34

500380506

ELBOW

35

855051617

O-RING

36

855051014

O-RING

37

500380872

'T'' UNION

38

855051014

O-RING

39

500365502

PLUG

40

855150033

GASKET
