Запчасти Komatsu WB97R-2 РАМА РАМА
18
21
14
17
15
11
16
13
22
6
7
5
8
9
10
8
12
3
9
23
3
2
4
17
20
19
1
1
312601052
FRAME VERTICAL STIRRUP
2
312601601
PLATE
3
802170007
WASHER
4
801880220
SELF-LOCKING NUT
5
312606603
BOLT
6
312605734
SQUAB PANEL
6
312605755
SQUAB PANEL
7
312605756
PLATE
8
802148013
WASHER
10
312701635
RIGHT PROTECTION
11
312701636
LEFT PROTECTION
13
801880001
SELF-LOCKING NUT
14
312605725
COVER
16
312610051
TUBES SUPPORT
17
808001069
DAMPER
19
801880220
SELF-LOCKING NUT
20
390605087
WASHER
21
802170007
WASHER
22
855710078
GASKET
23
312605106
PLATE
