Запчасти Komatsu WB95R-1 WB97R-1 РАМА СИСТЕМА УПРАВЛЕНИЯ

1

312201062

FRAME, VERTICAL OUTRIGGER

1

312201075

FRAME, VERTICAL OUTRIGGER

2

312201061

FRAME, HORIZONTAL OUTRIGGER

2

312201074

FRAME, HORIZONTAL OUTRIGGER

3

801852220

NUT

4

802070020

WASHER

5

312201678

PLATE

6

801070052

BOLT

7

801852216

NUT

8

808001031

DAMPER

9

802060016

WASHER

10

801014198

BOLT

11

801014047

BOLT

12

802148006

WASHER

13

855710061

GASKET

14

312205785

REAR CAM PROFILE

15

801852206

NUT

16

311305062

REAR PLATFORM

17

802148009

WASHER

18

801014067

BOLT

19

311305747

COVER

19

312334605

COVER (ONLY FOR JIG ARM)

20

801250261

SCREW

21

816212687

WASHER

22

312205744

RUBBER

23

312205787

R.H. MUDGUARD

24

312205788

L.H. MUDGUARD

25

801852210

NUT

26

802148013

WASHER

27

801014095

BOLT

28

311305059

PLATFORM

29

801014201

BOLT

30

312205667

R.H. COVER

31

312205668

L.H. COVER

32

801350065

SCREW

33

801014321

BOLT

34

312241606

BALLAST

35

802160014

WASHER

36

802070016

WASHER

37

801852216

NUT

38

885411049

GROMMET

39

802190006

SPRING WASHER

40

816214310

RUBBER

41

500411509

RUBBER

42

855710058

GASKET

43

312205745

RUBBER
