Запчасти Komatsu WB95R-1 WB97R-1 ПЕРЕДН. ПРИБОРНАЯ ПАНЕЛЬ КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

885270291

FRONT DASHBOARD, ASSY.

1

885270510

FRONT DASHBOARD, ASSY.

2

885141051

LAMP HOLDER

3

885140026

BULB

4

885141166

GLASS, OIL ENGINE PRESSURE

5

885141167

GLASS, OIL TEMPERATURE

6

885141118

GLASS, AIR FILTER CLOGGING

7

885141122

GLASS, ENGINE COOLANT THERMOMETER

8

885141120

GLASS, OIL ENGINE PRESSURE

9

885141117

GLASS, DIRECTION INDICATOR

10

885141119

GLASS, GENERATOR

11

885141111

GLASS, FUEL LEVEL INDICATOR

12

885141116

GLASS, HAND BRAKE

13

885141127

GLASS, 4WD

14

885141114

GLASS, SAIL LIGHT

15

885141115

GLASS, HEADLIGHT

16

885141164

GLASS, DIFFERENTIAL LOCKING

17

885081102

SWITCH

18

885141072

BULB

19

885141165

PUSHBUTTON

20

885141153

GLASS, REDUCTOR DISCONNECTING

21

801350042

SCREW

22

311305753

FRONT INSTRUMENT BOARD

23

885081086

GLASS, WARNING LIGHT

24

885141098

GLASS, CHECK SAFETY LAMP

25

885081092

SWITCH, EMERGENCY

26

885141101

GLASS, EMERGENCY

27

885081094

SWITCH

28

885141099

GLASS, HEATER

29

885411096

CONNECTOR

30

885411100

SWITCH HOLDER

31

885081089

SWITCH

32

885141107

GLASS, FRONT WORKING LIGHT

33

885081090

SWITCH, WIPER

34

885141104

GLASS, WIPER

35

885411099

PLUG

36

885411187

HORN

37

885071034

RELAY

38

885081113

COMMUTATOR, ASSY.

39

312208059

COMMUTATOR

40

312208613

UPPER COVER

41

312208612

COVER

42

801104043

SCREW

43

801104050

SCREW

44

802120005

SPRING WASHER

45

885270201

WIRING HARNESS, ASSY.

45

885270509

WIRING HARNESS, ASSY.

46

CTK100310

GEARBOX DRIVE, ASSY.

46

CK4224986

GEARBOX DRIVE, ASSY.

47

CK4201700

KNOB

48

CK4201684

PEG

49

CK4201696

BELOWS

50

CK4201716

GASKET

51

CK4201629

COVER

52

CK4201625

ADAPTOR

53

801104050

SCREW

54

802070005

WASHER
