Запчасти Komatsu WB95R-1 WB97R-1 КРЕПЛЕНИЕ ДВИГАТЕЛЯ ЧАСТЬ И МЕХ-М ОТБОРА МОЩНОСТИ (TURBO ДВИГАТЕЛЬ) КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

801852216

NUT

2

802060016

WASHER

3

808001031

DAMPER

4

312207076

SUPPORT, FRONT, R.H.

5

801014198

BOLT

6

801014130

BOLT

7

802150012

SPRING WASHER

8

312207075

SUPPORT, FRONT, L.H.

9

871120118

TURBO ENGINE

10

885070015

WATER TEMPERATURE TRANSMITTER

11

360707628

ADAPTOR

12

801050158

BOLT

13

802150510

SPRING WASHER

14

807001160

DRIVE SHAFT, ASSY.

14

807001168

DRIVE SHAFT, ASSY.

14

807001170

DRIVE SHAFT, ASSY.

15

802150510

SPRING WASHER

16

801014095

BOLT

17

312207077

SUPPORT, REAR, R.H.

17

312207119

SUPPORT, REAR, R.H.

18

312207652

SUPPORT, REAR, L.H.

19

CK4200573

SENSOR, REVOLUTION

19

CK4202485

SENSOR, REVOLUTION

20

CK0030020

O-RING

20

CKK030022

O-RING

21

CK4200589

CONNECTOR

22

802660500

HOSE-CLAMP

23

802070010

WASHER

24

801014093

BOLT

25

P2848A102

HIGH TEMPERATURE TRANSMITTER

26

CK4202488

SUPPORT

27

CK03GM612

SCREW
