Запчасти Komatsu WB95R-1 WB97R-1 НИЗ. PRESSURE ТОПЛИВН. СИСТЕМА (TURBO ДВИГАТЕЛЬ) ГОЛОВКА ЦИЛИНДРОВ

1

P4121T003

PIPE, FUEL

2

P33532128

NUT

3

P33811113

SLEEVE

4

P33532128

NUT

5

P33811113

SLEEVE

6

P36564422

HOSE-CLAMP

7

PK0180043

HOSE-CLAMP

8

P3437E006

PIPE, FUEL

9

P33225412

NUT

10

P33811112

SLEEVE

11

P33225412

NUT

12

P33811112

SLEEVE

13

PK0566004

SLEEVE

14

PK0095344

BOLT

15

PK0920146

WASHER

16

PK0920146

WASHER

17

PK0576112

NUT

18

PK0566003

SLEEVE

19

P4121M012

PIPE, FUEL

20

P33532128

NUT

21

P33811113

SLEEVE

22

P33532128

NUT

23

P33811113

SLEEVE

24

P4121K019

PIPE, FUEL

25

P33532128

NUT

26

P33811113

SLEEVE

27

P33532128

NUT

28

P33811113

SLEEVE

29

P2314E007

BOLT

30

P36511123

PLATE

31

P36844116

BRIDLE

32

P36844116

BRIDLE

33

P36511123

PLATE

34

P2318D205

NUT

35

P2314H003

BOLT

36

P3653R002

BRACKET

37

P2314F002

SCREW

38

P2314F006

BOLT

39

P2318A602

NUT

40

PK0920496

WASHER

41

P31726241

UNION

42

P33532129

NUT
