Запчасти Komatsu WB95R-1 WB97R-1 STICKER - WARNING ПЛАСТИНА МАРКИРОВКА

1

312214625

PLATE, OPERATION

2

312214626

PLATE, OPERATING ARM AND BUCKET

3

360714610

PLATE, OPERATING SHOVEL

4

312214627

PLATE, OPERATING LEFT OUTRIGGER

5

312214629

PLATE, OPERATING RIGHT OUTRIGGER

6

314516601

PLATE, LOCKING BRACKET

7

360714609

PLATE, HIGH SPEED

8

360714608

PLATE, LOW SPEED

9

802190004

SPRING WASHER

10

312214618

PLATE, EGS DEVICE

11

816214319

KIT, BASIC STICKER

11

816214399

KIT, BASIC STICKER

12

816214320

MARK PLATE KIT (WB95R)

13

816214321

MARK PLATE KIT (WB97R)

14

816211428

KIT, BACKHOE (ONLY FOR ITALY)

15

816210881

PLATE, MAX. SPEED 20 Km/h (GERMANY)

16

312214690

PLATE, RAISING CAPACITY (894)

16

312214691

PLATE, RAISING CAPACITY (SIDE DIGGING BOOM) (894)

16

312214692

PLATE, RAISING CAPACITY (898)

16

312214693

PLATE, RAISING CAPACITY (SIDE DIGGING BOOM) (898)

17

360714682

PLATE, BRAKING PEDAL (ITALY)

17

360714686

PLATE, PRAKING PEDAL (GERMANY)

17

360714690

PLATE, BRAKING PEDAL (FRANCE)

17

360714694

PLATE, BRAKING PEDAL (ENGLAND)

17

360714698

PLATE, BRAKING PEDAL (SPANISH)

17

360714702

PLATE, BRAKING PEDAL (PORTUGUESE)

18

355614628

PLATE, STICKERS (ONLY FOR GERMANY)

19

360714611

PLATE, OPERATING BUCKET 4 IN 1

20

312214706

PLATE, FKI

21

801852205

NUT

22

802148005

WASHER

23

312204622

PLATE, FORK POSITINING (ITALY)
