Запчасти Komatsu WB95R-1 WB97R-1 ГОРИЗОНТАЛЬН. ОПОРА МАРКИРОВКА

1

200513906

FOOT, L.H.

2

500252043

SPRING WASHER

3

802610117

PIN, COTTER

4

500323000

PIN

5

200513904

EXTENSION

6

802620009

PIN, COTTER

7

500611613

PIN

8

200513903

SUPPORT, L.H.

9

802610118

PIN, COTTER

10

500252039

WASHER

11

500217002

BUSHING

12

500250057

SPACER

13

860010007

FITTING

14

500322802

PIN

15

200513902

SUPPORT, R.H.

16

200513905

FOOT, R.H.

17

801703212

NUT (OPTIONA)

18

200513907

FOOT, R.H. (OPTIONAL)

19

200513908

FOOT, L.H. (OPTIONAL)

20

200513952

RUBBER (OPTIONAL)

21

802070016

WASHER (OPTIONAL)

22

801014184

BOLT (OPTIONAL)

23

200513909

FOOT, R.H. (OPTIONAL)

24

200513910

FOOT, L.H. (OPTIONAL)

25

801104290

SCREW

26

802040033

WASHER

27

801852224

NUT

28

801104292

SCREW

29

312315617

RETAINER

30

312315618

RING

31

802510189

PEG

32

200291724

CHAIN
