Запчасти Komatsu WB95R-1 WB97R-1 ФИКСИР. РУКОЯТЬ МАРКИРОВКА

1

200182151

FIXED ARM

1

312339071

FIXED ARM

2

312339300

PIN

3

802620103

PIN, COTTER

4

500322633

PIN

5

801014113

BOLT

6

801852210

NUT

7

801014125

BOLT

8

802150012

SPRING WASHER

9

312339604

SLIDE BLOCK, UPPER

10

801014209

BOLT

11

500252060

WASHER

12

312339610

SLIDE BLOCK, LOWER

13

200182150

MOVABLE ARM

14

500217005

BUSHING

15

500250064

SPACER

16

500217002

BUSHING

17

500250056

SPACER

18

860010007

FITTING

19

500044139

EXTENSION

20

500044110

EXTENSION

21

312339065

MOVABLE ARM (CASTING VERSION)

22

801466201

DOWEL

22

312439612

DOWEL

23

801920109

NUT

24

802070018

WASHER

25

312339627

DOWEL

25

312439612

DOWEL

26

380000509

SPACER
