Запчасти Komatsu WB95R-1 WB97R-1 ГИДРОЛИНИЯ (ВСАСЫВ. И ЛИНИЯ ПОДАЧИ) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

312206607

MOTOR FLANGE

2

802150455

SPRING WASHER

3

801050012

BOLT

4

807001130

DRIVE SHAFT

5

801104100

SCREW

6

802150008

SPRING WASHER

7

500532380

FLANGE

8

860010001

FITTING

9

801014069

BOLT

10

802150508

SPRING WASHER

11

500022672

SPACER

12

807001120

COUPLING

13

312201063

SUPPORT

13

312207094

SUPPORT

14

801014123

BOLT

15

802150012

SPRING WASHER

16

802070012

WASHER

17

840180001

HYDRAULIC PUMP, ASSY.

17

840180003

HYDRAULIC PUMP, ASSY.

18

801014125

BOLT

19

802150512

SPRING WASHER

20

801703210

NUT

21

855021834

O-RING

22

312210058

PIPE

23

802150512

SPRING WASHER

24

801104152

SCREW

25

802660059

HOSE-CLAMP

26

392153036

HOSE

27

312210053

FLANGE

28

801014068

BOLT

29

802150508

SPRING WASHER

30

855021229

O-RING

31

855021219

O-RING

32

500359057

FLANGE

33

802150510

SPRING WASHER

34

801104126

SCREW

35

855021214

O-RING

36

500357221

FLANGE

37

500354464

UNION

38

801104125

SCREW

39

392074001

HOSE

40

392205006

HOSE

41

802660028

HOSE-CLAMP

42

802660034

COLLAR

43

802070010

WASHER

44

801852210

NUT

45

801014095

BOLT

46

500355606

ELBOW

47

200342330

UNION

48

855051617

O-RING

49

500351710

UNION

50

855051617

O-RING

51

392075003

HOSE

52

845010225

VALVE

53

855150054

GASKET

54

500360822

UNION

55

855150078

GASKET

56

500358218

UNION

57

200342349

UNION

58

855051217

O-RING

59

500351742

UNION

60

855051119

O-RING

61

802090010

GASKET

62

200362190

PRESSURE TAKE-UP

63

802070010

WASHER

64

801014112

BOLT

65

801852210

NUT

66

844150045

CONTROL VALVE, ASSY.
