Запчасти Komatsu WB95R-1 WB97R-1 КАБИНА (/7) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

816210474

BASE

2

816213801

RIVET

3

816210473

TIE-ROD, ASSY.

4

816213808

COVER

5

816210475

PIN

6

816211479

SPACER

7

802070008

WASHER

8

816210648

NUT

9

802070012

WASHER

10

816211940

STRIKER

11

801250059

SCREW

12

802070006

WASHER

13

311305659

COVER

14

801200696

SCREW

15

816210642

LOCK, BLOCK

16

816210643

LOCK, BLOCK

17

801250059

SCREW

18

802148006

WASHER

19

801220206

SCREW

20

816213799

SPACER

21

816210641

GASKET

22

816213798

GASKET

23

311305085

HANDLE, R.H.

24

311305086

HANDLE, L.H.

25

816213375

PUSH BUTTON

26

311305741

CYLINDER

27

311305743

PIN

28

311305742

SPRING

29

311305744

BELLOWS

30

816213800

HOSE-CLAMP

31

801220193

SCREW

32

802070005

WASHER

33

816211903

PAD

34

802148006

WASHER

35

816211962

RETAINER

36

816211961

GASKET

37

816213802

SPACER

38

816211963

STRIKER

39

801014070

BOLT

40

802070008

WASHER

41

801852408

NUT

42

816213803

COVER

43

801852408

NUT
