Запчасти Komatsu WB95R-1 WB97R-1 КАБИНА (/7) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

311305716

PIN

2

802070012

WASHER

3

311305717

BUSHING

4

816213934

TIE-ROD, R.H.

5

816213935

TIE-ROD, L.H.

6

816213807

SPACER

7

802070010

WASHER

8

801862210

NUT

9

816213808

COVER

10

311305720

RETAINER

11

802070008

WASHER

12

801250072

SCREW

13

311305739

PIN

14

802510111

PEG

15

311305740

SPRING

16

802070006

WASHER

17

816213809

KNOB

18

816213910

CYLINDER

19

802070006

WASHER

20

801852206

NUT

21

816213689

COVER

22

816213794

SPACER

23

816213936

SUPPORT

24

802070008

WASHER

25

801104125

SCREW

26

802070008

WASHER

27

801852208

NUT

28

816213803

COVER

29

816213937

FOOT, R.H.

30

816213938

FOOT, L.H.

31

802070008

WASHER

32

801014068

BOLT

33

816213803

COVER

34

311305718

PIN

35

311305719

ROLLER

36

802070016

WASHER

37

802250017

RING, SNAP

38

802070010

WASHER

39

801024035

BOLT

40

816213808

COVER

41

816213939

LEVER

42

802070008

WASHER

43

801250056

SCREW

44

816213821

COVER

45

801370066

SCREW

46

801852208

NUT

47

816213932

SUPPORT

47

816214549

SUPPORT

48

802070005

WASHER

48

801250045

SCREW

49

801250045

SCREW

49

802070005

WASHER

50

816213931

SWITCH

50

816214548

SWITCH

51

801713412

NUT
