Запчасти Komatsu WB93S-5E0 -СЕКЦ. УПРАВЛЯЮЩ. КЛАПАН (8/) РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

\0

723-1A-15506

CONTROL VALVE, ASSEMBLY

1

723-11-29830

RETAINER

2

723-11-39840

SPRING

3

723-11-37251

CASE, SPRING

4

723-11-37540

CASE, SPRING

5

709-32-11760

O-RING

6

706-47-60230

BOLT

7

702-16-55270

BOLT

8

01252-60650

BOLT

9

01252-60640

BOLT, HEXAGON SOCKET HEAD

10

723-11-37371

RETAINER

11

723-11-29862

SPRING

12

01252-60612

BOLT

13

723-11-37360

PLATE

14

01023-10406

SCREW

15

723-11-37371

RETAINER

16

723-11-29862

SPRING

17

723-11-37360

PLATE

18

01252-60612

BOLT

19

01023-10406

SCREW

20

723-11-17330

RETAINER

21

723-11-17353

RETAINER

22

723-11-17341

SPRING

23

723-11-17361

BOLT

24

723-11-27880

CASE, SPRING

25

723-11-37220

CASE

26

723-12-19120

O-RING

27

01252-60620

BOLT

28

709-32-11580

SPRING

29

01252-60612

BOLT

30

723-11-37360

PLATE

31

01023-10406

SCREW
