Запчасти Komatsu WB93S-5E0 -СЕКЦ. УПРАВЛЯЮЩ. КЛАПАН (7/) РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

\0

723-1A-15506

CONTROL VALVE, ASSEMBLY

\0

723-1A-15507

CONTROL VALVE, ASSEMBLY

1

SPOOL

2

PLUG

3

O-RING

4

700-22-11291

RETAINER

5

723-26-14620

SPRING

6

723-26-15420

CASE

7

723-26-15810

PLATE

8

709-25-11290

SEAL

9

01252-60616

BOLT, HEXAGON SOCKET HEAD

10

723-11-37330

PLATE

11

01252-60612

BOLT

12

723-11-37341

BOOT

13

723-11-37360

PLATE

14

01023-10406

SCREW

15

723-11-37860

RETAINER

16

723-11-17440

SPRING

17

01252-60610

BOLT, HEXAGON SOCKET HEAD

18

723-11-37870

WASHER

19

723-11-37840

CASE

20

709-32-11530

SEAL

21

723-11-37350

PLATE

22

01252-60640

BOLT, HEXAGON SOCKET HEAD

23

723-11-37320

PLATE

24

01252-60612

BOLT

25

723-11-37360

PLATE

26

01023-10406

SCREW
