Запчасти Komatsu WB93S-5 ТРАНСМИССИЯ (/) РАМА

Схема запчастей Komatsu WB93S-5 - ТРАНСМИССИЯ (/) РАМА
14
13
12
10
8
6
15
11
4
9
2
7
21
5
22
3
18
19
1
16
20
7
37
17
9
35
33
6
36
31
8
23
10
28
34
32
27
26
30
24
24
29
25
23

Артикул

Название

Примечание

Количество

\0

42N-15-11100

TRANSMISSION, ASSY.

1

CA0025053

RING, SNAP

2

CA0027554

BEARING

3

CA0132813

SHIM, 0.050 mm

3

CA0132814

SHIM, 0.100 mm

3

CA0132815

SHIM, 0.300 mm

3

CA0133360

SHIM, 0.500 mm

4

CA0139010

SWING CIRCLE

5

CA0145134

GEAR

6

CA0132867

THRUST WASHER

\6

CA0132637

KIT, SYNCHRONIZER

7

CA0046305

RING

8

CA0046307

RING

9

CA0046306

RING

10

CA0046308

RING

11

CA0046304

HUB

12

CA0046303

SPRING

13

CA0046301

BALL

14

CA0046302

LOOSE PIECE

15

CA0046300

CHANGE SELECTOR

16

CA0145133

GEAR

17

CA0025061

RING, SNAP

18

CA0144661

GEAR

19

CA0024817

RING, SNAP

20

CA0024321

SPRING PIN

21

CA0138971

SHAFT

22

CA0138970

GEAR

\22

CA0138548

KIT, SYNCHRONIZER

23

CA0046329

RING

24

CA0046330

RING

25

CA0046328

HUB

26

CA0046327

SPRING

27

CA0046314

BALL

28

CA0046326

LOOSE PIECE

29

CA0046325

CHANGE SELECTOR

30

CA0138969

GEAR

31

CA0138985

SWING CIRCLE

32

CA0026190

BEARING

33

CA0025485

SEAL

34

CA0137303

FLANGE

35

CA0028623

O-RING

36

CA0129924

WASHER

37

CA0123918

BOLT

Выбрано товаров: 43
