Запчасти Komatsu WB93S-5 ТРАНСМИССИЯ (/) РАМА

Схема запчастей Komatsu WB93S-5 - ТРАНСМИССИЯ (/) РАМА
14
12
11
11
10
13
9
12
8
10
6
10
5
13
3
7
14
18
15
1
4
16
17
2
20
25
21
23
19
21
18
17
24
16
8
15
7
5
11
22
7
11
9
1
10
10
28
27
26

Артикул

Название

Примечание

Количество

\0

42N-15-11100

TRANSMISSION, ASSY.

1

CA0139197

SEAL

2

CA0024800

SNAP RING

3

CA0026160

BEARING

4

CA0139011

SWING CIRCLE

5

CA0027956

ROLLER BEARING

6

CA0138975

GEAR

7

CA0138986

SWING CIRCLE

8

CA0025067

RING, SNAP

9

CA0135020

DISK

10

CA0133924

DRIVING PLATE

11

CA0133972

DRIVEN PLATE

12

CA0025031

RING, SNAP

13

CA0133912

SPRING LOCK

14

CA0139351

SPRING

15

CA0138984

SLEEVE

16

CA0138983

PISTON

17

CA0139199

SEAL

18

CA0139198

SEAL

19

CA0068354

INLET SHAFT

20

CA0023835

PLUG

21

CA0024321

SPRING PIN

22

CA0138974

GEAR

23

CA0025811

BEARING

24

CA0024805

RING, SNAP

25

CA0142858

SEAL

26

CA0024785

RING, SNAP

27

CA0025735

BEARING

28

CA0138383

PROPELLER SHAFT

Выбрано товаров: 29
