Запчасти Komatsu WB93R-5E0 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

42N-54-13400

DOOR, L.H. ASSEMBLY

1

42N-54-13350

DOOR FRAME L.H.

2

42N-54-15370

ADAPTER

3

42N-54-13440

GASKET

4

42N-54-13430

GLASS

5

42N-54-13450

CAP

6

42N-54-13470

HINGE

7

42N-54-18690

SCREW

8

21D-54-13242

HANDLE

9

42N-54-17150

SCREW

10

42N-56-11910

WASHER

11

21D-54-13560

WASHER

12

21D-54-13250

SPACER

13

42N-54-17550

GASKET

14

42N-54-13520

HOOK

15

02890-01013

O-RING

16

42N-54-13500

GASKET

17

42N-54-13490

TEMPLATE

18

42N-54-13510

GASKET

19

42N-54-13530

SPRING

20

42N-54-13540

KNOB

21

42N-56-13580

BOLT

22

42N-54-13330

RUBBER

23

42N-54-18490

SCREW

24

42N-54-19280

WASHER

25

21D-54-13250

SPACER

26

42N-54-19190

NUT

27

42N-54-13480

COVER

28

42N-54-17250

SCREW

29

21D-54-13290

WASHER

30

21D-54-13230

LOCK

31

42N-54-15880

BOLT

32

01602-30825

WASHER

33

395-56-13600

NUT

34

42N-54-17320

SPRING

35

42N-54-13730

GAS SPRING

36

01640-31016

WASHER

37

42N-54-17270

NUT

38

21D-54-13780

PROTECTION

39

42N-54-13700

FIXED HINGE

40

42N-54-17930

PIN

41

04064-01210

RING, SNAP

42

42N-54-19660

BOLT

43

01643-11032

WASHER

44

21D-54-13310

PIN

45

42N-54-13720

HOOK

46

01640-21223

WASHER

47

395-56-13880

NUT
