Запчасти Komatsu WB93R-5 ТРАНСМИССИЯ (9/) РАМА

Схема запчастей Komatsu WB93R-5 - ТРАНСМИССИЯ (9/) РАМА
1
18
17
17
16
15
13
31
16
10
14
11
16
12
3
7
12
20
8
11
9
8
22
7
3
29
34
30
32
33
19
6
5
21
27
4
23
24
3
2
25
26
35
28
10

Артикул

Название

Примечание

Количество

\0

42N-15-12200

TRANSMISSION, ASSY.

1

CA0641986

CONTROL VALVE, ASSY.

2

CA0132922

PLUG

3

CA0028129

O-RING

4

CA0024898

RING, SNAP

5

CA0642892

PISTON

6

CA0132927

SPRING

7

CA0139863

SPRING

8

CA0132914

WASHER

9

CA0139861

PISTON

10

CA0068414

HOUSING, GEARS, ASSY.

11

CA0021581

PLUG

12

CA0023286

GASKET

13

CA0021322

PLUG

14

CA0023260

GASKET

15

CA0134125

PIPE

16

CA0028114

O-RING

17

CA0642096

SOLENOID

18

CA0642100

PLUG

19

CA0132912

HOLDER, DELIVERY VALVE

20

CA0021373

SCREW

21

CA0132919

GASKET

22

CA0139934

PLATE

23

CA0134084

PISTON

24

CA0134074

SPRING

25

CA0134075

SPRING

26

CA0134089

SPRING

27

CA0134086

PIN

28

CA0642891

SPRING

29

CA0041635

BALL

30

CA0132928

SPRING

31

CA0020807

BOLT

32

CA0130242

GASKET

33

CA0131328

PLATE, CONTROL VALVE

34

CA0021391

SCREW

35

CA0131329

GASKET

Выбрано товаров: 36
