Запчасти Komatsu WB93R-5 ТРАНСМИССИЯ (/) РАМА
14
13
12
10
8
6
15
11
4
9
2
7
21
5
22
3
18
19
1
16
20
7
37
17
9
35
33
6
36
31
8
23
10
28
34
32
27
26
30
24
24
29
25
23
\0
42N-15-11100
TRANSMISSION, ASSY.
\0
42N-15-12200
TRANSMISSION, ASSY.
1
CA0025053
RING, SNAP
2
CA0027554
BEARING
3
CA0132813
SHIM, 0.050 mm
3
CA0132814
SHIM, 0.100 mm
3
CA0132815
SHIM, 0.300 mm
3
CA0133360
SHIM, 0.500 mm
4
CA0139010
SWING CIRCLE
5
CA0145134
GEAR
6
CA0132867
THRUST WASHER
\6
CA0132637
KIT, SYNCHRONIZER
7
CA0046305
RING
8
CA0046307
RING
9
CA0046306
RING
10
CA0046308
RING
11
CA0046304
HUB
12
CA0046303
SPRING
13
CA0046301
BALL
14
CA0046302
LOOSE PIECE
15
CA0046300
CHANGE SELECTOR
16
CA0145133
GEAR
17
CA0025061
RING, SNAP
18
CA0144661
GEAR
19
CA0024817
RING, SNAP
20
CA0024321
SPRING PIN
21
CA0138971
SHAFT
22
CA0138970
GEAR
\22
CA0138548
KIT, SYNCHRONIZER
23
CA0046329
RING
24
CA0046330
RING
25
CA0046328
HUB
26
CA0046327
SPRING
27
CA0046314
BALL
28
CA0046326
LOOSE PIECE
29
CA0046325
CHANGE SELECTOR
30
CA0138969
GEAR
31
CA0138985
SWING CIRCLE
32
CA0026190
BEARING
33
CA0025485
SEAL
34
CA0137303
FLANGE
35
CA0028623
O-RING
36
CA0129924
WASHER
37
CA0123918
BOLT
