Запчасти Komatsu WB93R-5 ЦИЛИНДР ПОВОРОТА СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ

\0

707-02-07731

CYLINDER, ASSY.

1

707-76-55570

BUSHING

2

707-58-50H70

PISTON ROD

3

07179-12062

RING, SNAP

4

707-29-10700

CYLINDER HEAD

5

707-52-90250

BUSHING

6

707-36-10780

PISTON

7

01310-00820

DOWEL

8

707-76-50930

BUSHING

9

707-12-10230

CYLINDER

10

01310-00812

DOWEL

11

42N-6C-12420

THRUST WASHER

12

707-81-30080

THRUST WASHER

13

707-73-03010

RING, SNAP

14

707-71-50200

CYLINDER

\14

707-99-32070

KIT, GASKET

15

176-63-92240

GASKET

16

07000-12100

O-RING

17

707-51-50030

GASKET

18

707-51-50640

GASKET

19

07146-02096

RING, WEAR

20

07000-12095

O-RING

21

07001-03050

RING, WEAR

22

07000-13050

O-RING

23

707-44-10180

O-RING

24

07156-01012

PACKING ROD

25

02896-11009

O-RING

26

707-34-18020

O-RING

27

21D-09-89140

GREASE NIPPLE
