Запчасти Komatsu WB93R-5 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

42N-54-13400

DOOR, L.H., ASSY.

1

42N-54-13350

FRAME, DOOR

2

42N-54-13450

PLUG

3

42N-54-13440

GASKET

4

42N-54-13430

GLASS

5

42N-54-15370

BUSHING

6

42N-54-13470

HINGE

7

42N-54-18690

SCREW

8

21D-54-13241

HANDLE

9

42N-54-17150

SCREW

10

01643-10623

WASHER

11

21D-54-13560

WASHER

12

21D-54-13250

RUBBER

13

42N-54-17550

GASKET

14

42N-54-13520

SNAP PIN

15

02890-01013

O-RING

16

42N-54-13500

GASKET

17

42N-54-13490

LOCK

18

42N-54-13510

GASKET, INNER

19

42N-54-13530

SPRING

20

42N-54-13540

KNOB

21

01252-70816

BOLT

22

21D-09-86180

PROTECTION

23

42N-54-15840

BOLT

24

01640-30610

WASHER

25

01580-30605

NUT

26

42N-54-13480

COVER

27

42N-54-17250

SCREW

28

21D-54-13290

WASHER

29

21D-54-13230

LOCK, BLOCK

30

42N-54-15880

BOLT

31

01602-30825

WASHER

32

395-56-13600

NUT

33

42N-54-17320

CLAMP

34

42N-54-13730

GAS SPRING

35

01640-31016

WASHER

36

42N-54-17270

NUT

37

21D-54-13780

PROTECTION

38

42N-54-13700

HINGE

39

42N-54-17930

PIN

40

04064-01210

RING, SNAP

41

42N-54-19660

BOLT

42

01643-11032

WASHER

43

21D-54-13310

STRIKER

44

42N-54-13720

GUARD

45

01640-21223

WASHER

46

395-56-13880

NUT
