Запчасти Komatsu WB93R-2 ТРАНСМИССИЯ (WD) (/) РАМА

Схема запчастей Komatsu WB93R-2 - ТРАНСМИССИЯ (WD) (/) РАМА
13
14
11
10
12
8
7
14
9
13
6
15
5
4
17
3
2
12
18
16
19
1
23
21
25
21
18
17
24
22
16
9
15
5
20
9
7
1
8
10
28
11
27
26

Артикул

Название

Примечание

Количество

\0

200120073

GEAR SHAFT, ASSY

1

CA0139197

OIL SEAL

2

CA0024800

SNAP RING

3

CA0026160

BEARING

4

CA0139011

THRUST WASHER

5

CA0027956

NEEDLE BEARING BUSH

6

CA0138975

GEAR

7

CA0025067

LOCK RING

8

CA0135020

CLUTCH PLATE LOCK RING

9

CA0138986

THRUST WASHER

10

CA0133924

CLUTCH DRIVE PLATE

11

CA0133972

CLUTCH PLATE

12

CA0139351

SPRING

13

CA0133912

LOCK SPRING COVER

14

CA0025031

LOCK RING

15

CA0138984

CLUTCH SLEEVE

16

CA0138983

CLUTCH PISTON

17

CA0139199

OIL SEAL

18

CA0139198

OIL SEAL

19

CA0147454

INNER SHAFT

20

CA0138974

GEAR

21

CA0024321

SPLIT PIN

22

CA0025811

BEARING

23

CA023835

RIVET

24

CA0142858

OIL SEAL

25

CA0024805

SNAP RING

26

CA0024785

SNAP RING

27

CA0025735

BEARING

28

CA0138383

TRANSMISSION SHAFT

Выбрано товаров: 29
