Запчасти Komatsu WB93R-2 СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ

\0

871070073

TURBO ENGINE

1

YM129466-49300

ELBOW

2

YM123907-42000

PUMP, ASSY

3

YM23875-030000

PLUG

4

YM23875-020000

PLUG

5

YM119802-49112

PIPE

6

YM24190-080001

BALL

7

YM26106-080552

BOLT

8

YM26106-060502

BOLT

9

YM123900-42050

PACKING

10

YM123957-42450

PULLEY

11

YM123900-42480

BELT

12

YM123945-44750

FAN

13

YM123910-44771

SPACER

14

YM26106-100702

BOLT

15

YM123945-49810

THERMOSTAT CASE, ASSY

16

YM105010-39140

BOLT

17

YM123911-48620

THERMOSTAT

18

YM124610-49291

GASKET

19

YM123962-49500

THERMOSTAT COVER

20

YM123500-49550

GASKET

21

YM23876-030000

PLUG

22

YM26106-080252

BOLT

23

YM23387-040800

JOINT

24

YM23414-080000

GASKET

25

YM123900-49820

GASKET

26

YM26106-080702

BOLT

27

YM26106-080702

BOLT

28

YM123910-49050

PIPE

29

YM123910-49600

PIPE

30

YM123910-49610

PROTECTION

31

YM23000-025000

CLAMP

32

YM121250-44901

SWITCH

33

YM124465-44950

GASKET

34

YM121450-42450

PLUG

35

YM124465-44950

GASKET

36

YM123945-49610

PIPE, ASSY

37

YM123945-49700

CLAMP

38

YM123907-49710

PIPE

39

YM124722-59050

CLAMP

40

YM129486-59320

PROTECTION

41

YM123907-49620

PIPE, ASSY

42

YM123907-49720

PIPE

43

YM124722-59050

CLAMP

44

YM26106-060122

BOLT
