Запчасти Komatsu WB93R-2 ТРАНСМИССИЯ (WD) (/) РАМА

Схема запчастей Komatsu WB93R-2 - ТРАНСМИССИЯ (WD) (/) РАМА
22
23
11
7
8
24
13
13
12
14
12
27
2
25
1
21
26
3
15
16
10
15
4
18
9
14
6
19
20
17
9
18
19
5
15

Артикул

Название

Примечание

Количество

\0

200120058

DRIVE SHAFT, ASSY

1

CA0139449

FRONT HOUSING KIT

2

CA0021570

PLUG

3

CA0021557

PLUG

4

CA0021561

PLUG

5

CA0021582

PLUG

6

CA0139441

REAR HOUSING KIT

7

CA0021570

PLUG

8

CA0139278

BREATHER PIPE

9

CA0131364

UNION

10

CA0125280

OIL PLUG

11

CA0030368

BREATHER

12

CA0023260

COPPER WASHER

13

CA0021322

PLUG

14

CA0072259

PIN

15

CA0020852

BOLT

16

CA0131158

COVER

17

CA0130393

OIL PIPE

18

CA0023272

COPPER WASHER

19

CA0130663

BOLT

20

CA0132634

LUBRICATION PIPE

21

CA0028560

O-RING

22

CA0021009

BOLT

23

CA0138550

PROTECTION COVER

24

CA0028571

O-RING

25

CA0020858

BOLT

26

CA0025485

SEAL

27

CA0143687

SENSOR, OIL TEMPERATURE

Выбрано товаров: 28
