Запчасти Komatsu WB93R-2 ФИКСИР. РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

312739050

FIXED ARM

2

500044110

EXTENSION

3

500044139

EXTENSION

4

500322633

PIN

5

801880001

SELF - LOCKING NUT

6

801015569

BOLT

7

500322638

PIN

8

801880001

SELF - LOCKING NUT

9

801015568

BOLT

10

860030004

FITTING

11

312739051

MOVABLE ARM

12

500322645

PIN

13

802250040

RING SNAP

14

802610118

COTTER

15

312339300

PIN

16

802620103

COTTER

17

312339610

LOWER SLIDER

18

801920109

NUT

19

312339604

UPPER SLIDER

20

802150012

SPRING WASHER

21

801015137

BOLT

22

312439612

BOLT

23

802070018

WASHER

24

380000509

CYLINDER

25

500217001

BUSHING

26

801015584

BOLT

27

801880212

NUT

28

200200402

LEVER, R.H.

29

200200403

LEVER, L.H.

30

500322614

PIN
