Запчасти Komatsu WB91R-5E0 ПЕДАЛЬ ТОРМОЗА СИСТЕМА УПРАВЛЕНИЯ

\0

42N-54-10170

BRAKING CONTROL PEDAL, ASSY.

1

42N-33-11100

BRAKE PUMP, ASSY.

2

42N-54-15870

BOLT

3

01643-10823

WASHER

4

42N-33-11220

PIPE

5

42N-33-11210

PIN

6

21D-09-21750

NUT

7

22E-09-13210

FORK

8

42N-54-15590

PIN

9

04025-00532

SPRING PIN

10

395-56-11080

STOPPER

11

21D-09-21720

NUT

12

42N-54-15560

BRAKE PEDAL, L.H.

13

42N-54-15550

BRAKE PEDAL, R.H.

14

09350-02020

BUSHING

15

42N-54-15570

WASHER

16

42N-54-15610

PIN

17

04064-01410

RING, SNAP

18

37A-09-61024

PIN

19

37B-09-2C016

SPRING

20

SUPPORT

21

395-56-13600

NUT

22

01643-10823

WASHER

23

42N-33-11230

HYDRAULIC TANK, ASSY.

24

42N-33-11240

PLUG

25

22E-62-11141

PRESSURE SWITCH

26

37D-09-4C754

UNION

27

37B-09-88006

O-RING

28

42N-62-16550

PIPE, L.H.

29

42N-62-16560

PIPE, R.H.

30

42N-54-17920

COLLAR

31

395-56-13500

BOLT

32

01643-10623

WASHER
