Запчасти Komatsu WB91R-5 МАРКИРОВКА (/) МАРКИРОВКА

Схема запчастей Komatsu WB91R-5 - МАРКИРОВКА (/) МАРКИРОВКА
8
9
1
8
10
15
7
6
5
11
4
3
14
2
15
8
1
16
21
20
19
17
18
16
8
1
8
15
22
4
26
25
3
14
15
8
1
27
23
2
28
16
29
16
31
32
33
30
12
13
b
a
a
b
24

Артикул

Название

Примечание

Количество

1

42N-93-11380

MARK PLATE, DANGER WORK AREA

2

42N-93-11670

MARK PLATE, SWL 1000 kg

3

42N-93-11220

MARK PLATE, DANGER PINCH POINT

4

09690-P0800

MARK PLATE, KOMATSU

5

37A-98-12210

PLATE, SAFETY, HYDRAULIC OIL

6

42N-93-12610

MARK PLATE, FUSES

7

42N-93-11650

MARK PLATE, BRAKE OIL

8

395-93-11330

MARK PLATE,

9

42N-93-11270

PLATE, SAFETY, ELECTRIC SOCKET

10

42N-93-11130

PLATE, READ MANUAL

11

42N-93-11190

MARK PLATE, FUEL LEVER

12

42N-93-11310

PLATE, OPERATING SWING LOCK LEVER

13

42N-93-11320

MARK PLATE, BOOM

14

42N-93-11510

MARK PLATE, UTILITY

15

09690-P0560

MARK PLATE, KOMATSU

16

42N-93-11360

MARK PLATE, ANCHOR POINTS

17

37A-98-12290

PLATE, SAFETY, HYDRAULIC OIL LEVEL

18

37A-98-12260

PLATE, SAFETY, ENGINE AIR FILTER

19

37A-98-12240

PLATE, SAFETY, FUEL

20

395-93-11430

MARK PLATE, TRANSMISSION OIL

21

37A-98-12250

PLATE, SAFETY FUEL FILTER

22

37A-98-12270

PLATE, COOLANT

23

37A-98-12230

PLATE, SAFETY, ENGINE OIL FILTER

24

37A-98-12340

PLATE, COOLANT

25

42N-93-11370

PLATE, SAFETY, DO NOT OPEN ENGINE HOOD

26

42N-93-11260

MARK PLATE, SAFETY, EMERGENCY EXIT

27

42N-93-11350

MARK PLATE, DANGER, START INCORRECTOR START

28

37A-98-12310

PLATE, SAFETY, HYDRAULIC OIL FILTER

29

395-93-11420

MARK PLATE, TRANSMISSION FILTER

30

42N-93-11630

MARK PLATE, KOMATSU

31

42N-93-11230

MARK PLATE, KOMATSU

32

21D-09-21420

NUT

33

37A-09-4A005

WASHER

Выбрано товаров: 33
