Запчасти Komatsu WB91R-5 ЦИЛИНДР СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ

\0

707-00-0Y942

CYLINDER, ASSY.

1

707-76-60750

BUSHING

2

721-58-60580

PISTON ROD

3

707-71-91280

DOWEL

4

07179-12074

RING, SNAP

5

707-29-12500

CYLINDER HEAD

6

707-52-90350

BUSHING

7

707-36-12630

PISTON

8

01314-20812

DOWEL

9

707-71-60190

PIN

10

04260-00635

BALL

11

721-11-12932

CYLINDER

12

707-76-60740

BUSHING

13

707-87-25390

PLUG

14

707-88-36770

GASKET

15

707-80-13020

SPRING

16

707-83-13040

VALVE

\16

707-99-41270

KIT, GASKET

17

07145-00060

GASKET

18

141-63-93270

GASKET

19

07000-12120

O-RING

20

707-51-60030

GASKET

21

707-51-60640

GASKET

22

07146-02116

RING, WEAR

23

07000-12115

O-RING

24

07000-13042

O-RING

25

07156-01215

PACKING ROD

26

707-44-12180

GASKET

27

02896-11018

O-RING

28

21D-09-89140

GREASE NIPPLE
